6KW ON GRID SOLAR SYSTEM - AC MODULE
6KW (580Wp - 620Wp Topcon) solar power generating system using the world's latest technology in a solar panel called Solar AC Module.
A 6kW Waaree/Vikram solar system generates 25-30 units a day from morning 9 am to 5 pm which is sufficient to run Light , Fan Refrigerator, Motor, Television, CCTV during the day from small 3-4 bhk home.- Enphase energized complete solution to generate 5 kW power, and 20-25 kWh energy everyday.On-Grid (Grid-Tied) Solar System :
A solar system which works with the grid is called on-grid or grid-tied solar system, there are three components in this system, such as
- #1. Panels, (Topcon or HJT Bifacial)
- #2. Inverters, (Enphase Microinverters)
- #3. Installation Kit (BOS)
Advantage :
- Generate power for your home usage and Export Excess electricity to TNEB.
- 4 years payback time and free electricity for next 20 years
Disadvantage :
- Does not come with backup, the system does not work when there is a power cut.
Product Details
Product OverviewSolar Panel
580-620 Watt Topcon Module - Bi-facial
(Waaree ,Vikram , Renewsys , UTL , Luminous ) - 10Nos
Space required
580 sq.ft. + Maintenance space
1 Panel dimension
Length – 6.9 feet, width – 3.8 feet
Mounting structure
GI / AL for 10 panels (5*2) Portrait pattern*
Micro-Inverter
IQ 8P - 10 NOS with all BOS
Solar Panel | 580-620 Watt Topcon Module - Bi-facial (Waaree ,Vikram , Renewsys , UTL , Luminous ) - 10Nos |
Space required | 580 sq.ft. + Maintenance space |
1 Panel dimension | Length – 6.9 feet, width – 3.8 feet |
Mounting structure | GI / AL for 10 panels (5*2) Portrait pattern* |
Micro-Inverter | IQ 8P - 10 NOS with all BOS |
ACMCB, ACDB , Earthing kit ,Lightining arrestor - Included |
Standard installation - Included, Civil work and Structure excluded* |
| Microinverter Efficiency : 97% |
| ENVOY MONITORING SYSTEM - INCLUDED IN THIS PACKAGE * . |
