2 KW ON GRID SOLAR SYSTEM - LOOMSOLAR
LOOM SOLAR 2KW COMPLETE ON GRID SOLAR SYSTEM
Loom solar 2kW(440W) solar power generating system using the world's latest technology in a solar panel called Solar AC Module.
A 2 kW solar system generates 8-10 units a day from morning 9 am to 5 pm which is sufficient to run Refrigerator, Television, Fans and lights during the day from small 2-3 bhk home.- Enphase energized complete solution to generate 2 kW power, and 7-10 kWh energy everyday.
A solar system which works with the grid is called on-grid or grid-tied solar system, there are three components in this system, such as
- #1. Panels, (Mono- Perc)
- #2. Inverters, (Microinverters)
- #3. Installation Kit
- Loom solar panel powered by enphase microinverter, with no single point of failure, and hence higher production.
- Burst technology that enables production even at low light and dusk conditions.
- Higher resistance against corrosion. Dustproof and waterproof microinverters.
- Safest system due to AC distribution structure, rather than DC structure of string inverter systems.
- Rapid shutdown technology will prevent system damage in case of grid failure.
- Warranty- 25 year warranty on panels, and Micro-inverters. 2 year warranty on Envoy.
Advantage :
- Generate power for your home and Export Excess electricity to TNEB.
- 4 years payback time and free electricity for next 20 years
Disadvantage :
- Does not come with backup, the system does not work when there is a power cut.
Solar Panel | Shark 440 watt Mono perc Module - Half cut technology . |
Space required | 160 sq.ft. |
1 Panel dimension | Length – 6.9 feet, width – 3.4 feet |
1-panel weight | 25 kg |
Micro-Inverter | IQ 7A ACM - 05 NOS |
Package components :
Shark 440W solar ac module - 05 Nos |
Mounting Structure - 01 No AC Wire - 40Mtrs |
Q Cable , Connectors, ACMCB,ACDB , Earthing kit. |
Standard installation - Included, Civil work excluded |
Microinverter Efficiency : 97% |
ENVOY MONITORING SYSTEM - INCLUDED IN THIS PACKAGE * . |
